Introducing anyPin DMD+ NVRAM Battery Eliminator. The low cost version of anyPin NVRAM that will work in all DMD pinball machines manufactured up to 2006*, *PLUS* Williams/Bally System 9, System 11, Bally 6803 and Data East games that originally used 6116 RAM. Any game that originally used either 6116, 6264 or 62256 RAM will work with an anyPin DMD+!
The original anyPin NVRAM Battery Eliminator was first released two years ago, the goal was to have a single part to eliminate batteries in pinball machines. The original anyPin NVRAM option is still available with the Universal anyPin NVRAM and works in most every solid state pinball machine ever made.
*Stern games manufactured before 2006 (Whitestar), all WPC, System 9, System 11, 6803, Sega, and Data East machines are fully compatible with anyPin DMD+. Stern games made after 2006 and Gottlieb System 3s are not compatible.
anyPin DMD+ Set as 6264
anyPin DMD+ Set as 6116
Williams System 8, System 9, and System 11, and Bally 6803 games require 10K Ohm resistors at R1 and R2 to be installed on the bottom of anyPin DMD+. If you indicate in the notes of your order that you're installing into one of these games, the needed resistors will be installed prior to shipping.
R1 and R2 populated with 10K Ohm through-hole resistors is perfectly fine.
Since the 6116 RAM is a smaller chip (24 pins compared to 28 pins on a 6264) the four front pins on anyPin will overhang out of the socket when being used as a 6116. Align "Pin 1 6116" on anyPin to pin one of the RAM socket on the board.
